5G router Support VPN, more functions for more application scenes Optional to support dual SIM: eSIM+SIM
Product Description
KS-LTE517-Cat6 is an high speed, high performance, multiple functions LTE CPE in Cat6 standard. Comply with IEEE 802.11ac wireless standard, the wireless speed up to 1200Mbps in 2.4GHz and 5.8GHz. Support 4G FDD/TDD, WCDMA and GSM networking, plug and play, easy to have the high speed wireless network for 32+ end users. Support VPN, optional battery, it is best choice for ISP, home and some chain stores.
Main Features:
- Support 4G/WCDMA/GSM network, plug and play, easy to install;
- 2.4GHz+5.8GHz, the wireless speed up to 1200Mbps, 32+ end users can access into it;
- Support DC power, 2600mAh or 5200mAh battery optional, movable wireless router make network available everywhere;
- Support VPN, more functions for more application scenes;
- Optional to support dual SIM: eSIM+SIM
- Provide deeply firmware support, help customer to develop their own firmware;
Product Parameters
| Hardware Spec: |
| Model |
KS-LTE517-Cat6 |
| WiFi Standard |
IEEE 802.11b/g/n/ac |
| CPU |
MT7628+MT7613 |
| Flash |
8MB |
| Memory |
64MB |
| Frequency |
2.4G: 2400 - 2484MHz
5.8G: 5180~5825MHz |
| Data Rate |
300Mbps @ 2.4GHz
900Mbps @ 5.8GHz |
| RF Power |
2.4G≤20 dBm/chain
5.8G≤20 dBm/chain |
| Access Users |
32+ Clients |
| Interface |
1*10/100Mbps RJ45 port, WAN/LAN port |
| 2*10/100Mbps RJ45 ports, LAN ports |
| 1*SIM card slot for 3G/4G SIM card |
| 1*Power button to switch on/off power |
| 1*Reset button/WPS button |
| 1*DC power injector, 12V/1A power adapter |
| LED Indicator |
Power |
| ETH |
| 4G Signal strength (S1~S4) |
| Wi-Fi Antenna |
Build in 5dBi MIMO Antenna |
| 4G Antenna |
Inner 4G antenna, 5dBi; Optional External detachable antenna |
| Power Consumption |
<12W |
| DC Power Supply |
Input 12V / 1A (DC); |
| Battery |
2600mAh or 5200mAh(Optional) |
| MTBF |
≥52000H@25ºC |
| Working temperature |
Working Temperature:-20ºC~45ºC |
| Storage temperature: -40ºC~70ºC |
| Humidity |
5%~95% |
| Dimensions |
178*125*33mm |
| Firmware Features |
| Operation mode |
WAN/4G (WAN only, 4G only, WAN fist, 4G backup) |
| APN |
Support auto APN and manual APN |
| Wireless Functions |
Support guest SSID, SSID hidden |
| Support firewall such as MAC filter, IP filter |
| Support scheduled Wi-Fi on/off |
| VPN |
Open VPN and VPN Client (L2TP PPTP) |
| Security |
Open, WPA, WPA2PSK_TKIPAES, WAP2_EAP |
| IP Protocol |
IPv4 |
| Device Management |
GUI web management |
| Support firmware back-up, restore, reset, upgrade |
Packing List
|
KS-LTE517*1
Power Adapter*1
LAN Cable×1(1 meter)
User Manual×1
|
| 4G Data Rate |
| 4G protocol |
Cat6 |
| 3G/4G bands for Europe/Middle East |
B1/B3/B5/B7/B8/B20/B28@FDD;
B38/B40/B41@TDD,
2xCA: B1+B1/B3/B5/B8/B20/B28;
B3+B3/B5/B7/B8/B20/B28;
B7+B5/B7/B8/B20/B28;
B38+B38, B40+B40; B41+B41;
B1/B5/B8@WCDMA; |
| LTE-FDD Speed |
Downlink: 300Mbps, Uplink: 50Mbps |
| LTE-TDD Speed |
Downlink: 220Mbps, Uplink: 30Mbps |
| UMTS: |
HSDPA: Downlink: 21Mbps, HSUPA: Uplink: 5.76Mbps; WCDMA: max. 384kbps in downlink and uplink; |
Detailed Photos
Packaging & Shipping
Carton box: 41*25*39cm;
20PCS/CTN
After Sales Service
Two years warranty
FAQ
Q1. 4G bands:
A: Can customize the bands if not support
Q2. OEM & ODM service
A: OEM: provide your LOGO to us, we can add your LOGO on the product, firmware and package;
Content will be limited by MOQ;
ODM: we can provide PCBA, housing and firmware ODM service:
PCBA: 2~3 month to finish it;
Housing: 2 month after finish the PCBA;
Firmware: we can provide the open source driver for customer to develop their firmware;
We can provide DTS files if want;
And we can provide technical support in customer firmware development.
Q3. If support out of China production:
A. Yes, this is developed by our engineers, we can support SKD and CKD;
We can provide the SOP of assemble and finished product testing;
But for the CKD, firstly you can do the RF calibration, 2nd you should have engineer to debug the problem;
We can provide SOP or all documents, and we can send engineers to provide technical support, but will be costly.
